CEP-2
Heat Shrinkable Sleeve for
Directional-drilled Crossings
1.Composing of CEP-2 Heat
Shrinkable Sleeve for Directional-drilled Crossings.
The CEP-2 Heat Shrinkable
Sleeve for Directional-drilled
be constituted by
Central Heat Shrinkable Sleeve/tape and Heat
Shrinkable Sleeve/tape be
strengthened that width is 150-200mm with the
liquid epoxy primer.CEP-2T is Heat Shrinkable Tape.
2. Product description
When joint Heat
Shrinkable Sleeve /Tape installation completed, the
50% width of Heat Shrinkable Sleeve/Tape
strengthened that width is150-200mm, lap on the
joint heat shrinkable sleeve /Tape , the other 50% on
the pipe coating . It often used at front end of joint
Heat Shrinkable Sleeve/Tape along its
Directional-drilled Crossings. The Heat Shrinkable
Sleeve (Tape) with the liquid epoxy primer is applied
on the pipe joint which has three-layers.
3. Specification
3.1 Thickness of CEP-2Heat Shrinkable Sleeve
3.1.1 Specification of CEP-2T directional drilled heat shrinkable sleeve
Product |
Type |
Specification(mm) |
DN. |
Width |
Backing Thickness |
Adhensive Thickness |
Directional Drilled Corssing Heat Srhinkable Sleeve |
CEP-2T |
as customer's requirement |
450、500 |
≥1.5 |
≥1.2 |
The production sleeve(sacrifice sleeve)can be supplied as the customers' requirements:
width:150mm-200mm
3.1.2 Thickness of the closure patch
Product |
Width（mm） |
Thickness（mm） |
Length（mm） |
Closure Patch ofCEP-2T
|
70、100、120、150 |
≥1 |
as same as sleeve axial length before shrinking |
|
