CEP Steel Casing Crossing



Product Description

CEP Steel Casing Crossing is a field applied heat shrinkable wraparound sleeve designed for road, river crossing and other purposes. The inner layer is two-components epoxy primer which coated steel pipe; the middle layer is hot melt adhesive; the outer layer is the modified radiation crosslinked polyethylene backing.

Product Standard



Specification

Name

Type

Specification(mm)

DN.

Width

Backing Thickness

Adhensive Thickness

Steel Casing Crossing

CEP

Φ400

450、500

≥1.2

≥1.0

Steel Casing Crossing

CEP

Φ400

500、520

≥1.5

≥1.0

Features and Benefits

CEP Steel Casing Crossing heat shrinkable wraparound sleeve is mainly applied to pipe joint corrosion protection, reducer, and seal of valve. It has the high-performance heat sensitive adhesive effectively bonds to steel substrates and common pipeline coatings including polyethylene, polypropylene, fusion bonded epoxy and coal tar epoxy to form a reliable seal protection.

 Excellent coating compatibility

CEP Steel Casing Crossing heat shrinkable wraparound sleeve can be applied to a wide range of pipe coating including 2 layers polyethylene, 3 layers polyethylene, 3 layers polypropylene, fusion bonded epoxy, insulated jacket, coal tar primer. It can be used for corrosion protection of pipe joint and corrosion seal of reducer or valve. The effectiveness and excellence have been approved by many pipeline projects.

Apply with the primer at "wet state"

CEP Steel Casing Crossing heat shrinkable wraparound sleeve is applied on the "wet state" of primer allowing formation of strong mechanical and chemical bonds, allows fast application, combined with high performance.

Rapid installation

The adoption of new materials and new technology further predigests the installation. The liquid epoxy primer provided by XIPU can be used at a low preheating temperature which between 40 ºC~60ºC, quick, reliable field installation is easy to accomplish.

Long term corrosion protection

CEP Steel Casing Crossing heat shrinkable wraparound sleeve provides excellent resistance to soil creeping stresses and chemical attack, resulting in effective long-term corrosion protection. The high performance crosslinked backing in combination with adhesive can be engineered for different environment.
